high-pressure hydraulic hose crimping machine cable press hose fitting crimper wire rope tube decreasing price for sale
Equipment Overview
1. Mainly used for automatic high-voltage cable processing, which
can complete the functions of wire feeding,
peeling, weaving net, copper close-loop crimping, inner core peeling, waterproof plug, terminal crimping, sheath
and so on.
2, The whole machine adopts PLC bus control communication and a
full servo power system, which guarantees stable performance.
3, Touch screen operation. All processing parameters are able to
record and production content edit are able to edit send
upon request.
4, With imported servo motor and CCD visual detection function, it
gives you real-time monitoring of the process
quality to ensure product yield.
5. The machine adopts high precision servo motor and PM-01 pressure
management system, high precision and
strong stability, real-time monitoring of the process.
Technical Parameters
| Function | Fixed length cutting at both ends, stripping, terminal crimping, adjusting the height on the touch screen, discharging defective products while selecting | Capacity | 18 sec per single-sided loading (Length output depends on wire length and housing/terminal combinations) |
| Crimping Capacity | 10 tons and15 Tons Servo motor with mute specification (Customized according to the requirements of products) | Block Feed | Linear-carrier housing transferring/ Plate-loop conveying housing
feeding module (According to customer requirements) |
| Wire Cross-sections | 2.5 – 16 mm² (AWG 14 – 5) | Process Monitoring (integrated) | CCD Terminal Detection Crimping Force Monitoring |
| Feeding Wire Length | 600-9999mm | Electrical Connection | 3 phase/380v/50HZ(machine comes with a transformer) |
| Outer Layer Cutting | 0-60mm, stripping precision ±0.5mm can be full stripping and half stripping; The cutting precision is 0.05mm. | Power | 25KW |
| Laser stripping aluminum foil | 3-50mm, the residual length of one circle of aluminum foil is less than the thickness of the outer insulation layer, the residual size of the sharp corner is much less than or equal to 4.5mm, and the cutting accuracy is ±1mm, which does not harm the woven net and insulation layer | Compressed Air | 0.5-0.7Map |
| Screening Can Cutting | 5-55mm, cutting accuracy ±0.4mm | Optional | Max.12 PCS Crimping Module ((with programmable crimp height) |
| Screening Can Reversal | 5-20mm | Quality Assurance | Pull force Height Crimp-height Measurement Seal Module RXM Linquan MES System Laser Inkjet Print Tinning Twisting Stranded Wire |
| Inner Skin Cutting | 0-55mm, stripping precision ±0.5mm can be full Stripping and half stripping; The cutting precision. ±0.05mm |
Product advantages
Flexible platform design
Short changeover time
|
|
